New 2025 Yamaha YZ85LW
Vehicle Details
- Stock #: YM6763
- VIN: JYACB16C4SA006763
- Engine: 85 cc (5.2 ci) Liquid cooled Single-Cylinder
- Exterior Color: BLUE
- Transmission: Manual
Similar Vehicles
Frequently purchased together
Please select accessories from the list.
Click on the accessory link below to get more details.
Click on the accessory link below to get more details.
Standard Specifications
- Engine Type: Single-Cylinder
- Cylinders: 1
- Engine Stroke: 2-Stroke
- Cooling: Liquid
- Valve Configuration: Reed Valve
- Bore (mm): 47.5
- Bore (in): 1.87
- Stroke (mm): 47.8
- Stroke (in): 1.89
- Displacement (cc): 85
- Displacement (ci): 5.2
- Compression Ratio: 8.2
- Starter: Kick
- Fuel Requirements: Regular
- Compression Ratio (Secondary): 9.6:1
- Fuel Type: Gas / Oil Premix
- Carburetion Brand: Keihin
- Carburetor: Yes
- Number Of Carburetors: 1
- Carburetor Size (mm): 28
- Carburetion Type: Carburetor
- Transmission Type: Manual
- Number Of Speeds: 6
- Overdrive: Yes
- Primary Drive (Rear Wheel): Chain
- Gear Ratio (1): 2.46
- Gear Ratio (2): 1.89
- Gear Ratio (3): 1.53
- Gear Ratio (4): 1.29
- Gear Ratio (5): 1.13
- Gear Ratio (6): 1
- Length (in): 74.6
- Length (mm): 1894.8
- Width (in): 29.9
- Width (mm): 759.5
- Height (in): 46.3
- Height (mm): 1176
- Wheelbase (in): 50.6
- Wheelbase (mm): 1285.2
- Ground Clearance (in): 14.2
- Ground Clearance (mm): 360.7
- Length (ft): 6.22
- Length (ft/ft): 6
- Length (ft/in): 2.6
- Wet Weight (lbs): 165
- Wet Weight (kg): 74.8
- Fuel Capacity (gal): 1.3
- Fuel Capacity (l): 4.9
- Engine Displacement to Weight (cc): 0.52
- Frame: Steel
- Body Material: Plastic
- Foot Peg Location: Driver
- Chain Guard: Yes
- Chassis Protectors: Yes
- Fork Guards: Yes
- Front Suspension Type: Inverted Fork
- Front Suspension Size (in): 1.4
- Front Suspension Size (mm): 36
- Front Travel (in): 10.8
- Front Travel (mm): 274.3
- Front Adjustable Fork Pre-Load: Yes
- Front Adjustable Rebound Damping: Yes
- Front Suspension Brand Name: KYB
- Rear Suspension Type: Twin Sided Swing Arm
- Rear Travel (in): 11.3
- Rear Travel (mm): 287
- Rear Adjustable Shock / Spring Pre-Load: Yes
- Rear Adjustable Rebound Damping: Yes
- Number Rear Shock Absorbers: 1
- Rear Suspension Brand Name: KYB
- Rear Suspension Material: Aluminum
- Wheels Composition: Aluminum
- Tube / Tubeless: Tubed
- Front Wheel Width (in): 1.4
- Rear Wheel Width (in): 1.6
- Chromed: Yes
- Tire Brand: Dunlop®
- Front Tire Width: 70
- Front Tire Aspect Ratio: 100
- Front Wheel Diameter: 19
- Rear Tire Width: 90
- Rear Tire Aspect Ratio: 100
- Rear Wheel Diameter: 16
- Front Tire (Full Spec): Dunlop® GeoMax MX3SF® 70/100 R19
- Rear Tire (Full Spec): Dunlop® GeoMax MX3S® 90/100 R16
- Front Brake Type: Hydraulic Disc
- Front Brake Diameter (in): 8.7
- Front Brake Diameter (mm): 220
- Rear Brake Type: Hydraulic Disc
- Rear Brake Diameter (in): 7.5
- Rear Brake Diameter (mm): 190
- Seat Type: One-Piece
- Seat Material: Vinyl
- Seat Location: Driver
- Seat Height (in): 34.8
- Seat Height (mm): 883.9
- Number Of Seats: 1
- Primary Color: Blue
- Paint Swatch File Name: Yamaha/Team_Yamaha_Blue.gif
- Steering Control: Handlebar
